This inverter is built in isolation transformer to provide pure power to connected devices. It also can be parallel operated with 4 units and expand the total capacity to 120KW. Users can easily expand their existing power rating by adding inverters.
InfiniSolar TX-PA 30KW
Parallel operation up to 4 units
Overview
Main Features
- Pure sine wave output
- Self-consumption and Feed-in to the grid
- Programmable supply priority for PV, Battery or Grid
- True galvanic isolation transformer design
- User-adjustable charging current
- Programmable multiple operation modes: Grid-tie, off-grid and grid-tie with backup
- Built-in timer for various mode of on/off operation
- Multiple communication for USB, RS-232, Modbus and SNMP
- Monitoring software for real-time status display and control
- Parallel operation up to 4 units
Specifications
| MODEL | InfiniSolar TX-PA 30KW | |
| Maximum PV Input Power | 45KW | |
| Rated Output Power | 30KW | |
| Maximum Charging Power | 30KW | |
| GRID-TIE OPERATION | ||
| PV INPUT (DC) | ||
| Nominal DC Voltage / Maximum DC Voltage | 720 VDC / 950 VAC | |
| Start-up Voltage / Initial Feeding Voltage | 500 VDC / 550 VDC | |
| MPPT Voltage Range | 460 VDC ~ 900 VDC | |
| Number of MPP Trackers/Max. Input Current | 1/1x72A | |
| Full power MPP Voltage Range | 625 VDC ~ 900 VDC | |
| GRID OUTPUT (AC) | ||
| Output Frequency Range | 49 ~ 51 Hz or 59.3 ~ 60.5 Hz | |
| Nominal Output Voltage | 230 VAC* (P-N) / 400 VAC (P-P) | |
| Output Voltage Range | 195.5 - 253 VAC per phase | |
| Nominal Output Current | 43.5 A per phase | |
| Power Factor | 1 | |
| EFFICIENCY | ||
| Maximum Conversion Efficiency (DC/AC) | 95% | |
| OFF-GRID OPERATION | ||
| AC INPUT | ||
| AC Start-up Voltage / Auto Restart Voltage | 150 - 170 VAC per phase / 180 VAC per phase | |
| Acceptable Input Voltage Range | 170 - 280 VAC per phase | |
| Maximum AC Input Current | 43.5 A per phase | |
| PV INPUT (DC) | ||
| Maximum DC Power / Maximum DC Voltage | 45KW / 950 VDC | |
| MPPT Voltage Range | 460 VDC ~ 900 VDC | |
| Number of MPP Trackers/Max. Input Current | 1/1x72A | |
| BATTERY MODE OUTPUT (AC) | ||
| Nominal Output Voltage | 230 VAC (P-N) / 400 VAC (P-P) | |
| Output Waveform | Pure sine wave | |
| Efficiency (DC to AC) | >91% | |
| HYBRID OPERATION | ||
| PV INPUT (DC) | ||
| Nominal DC Voltage / Maximum DC Voltage | 720KW /950 VDC | |
| Start-up Voltage / Initial Feeding Voltage | 500 VDC / 550 VDC | |
| MPPT Voltage Range | 460 VDC ~ 900 VDC | |
| Number of MPP Trackers/Max. Input Current | 1/1x72A | |
| GRID OUTPUT (AC) | ||
| Nominal Output Current | 43.5 A per phase | |
| Nominal Output Voltage | 230 VAC* (P-N) / 400 VAC (P-P) | |
| Output Frequency Range | 49 ~ 51 Hz or 59.3 ~ 60.5 Hz | |
| Output Voltage Range | 195.5 - 253 VAC per phase | |
| Power Factor | 1 | |
| AC INPUT | ||
| AC Start-up Voltage / Auto Restart Voltage | 150 - 170 VAC per phase / 180 VAC per phase | |
| Acceptable Input Voltage Range | 170 - 280 VAC per phase | |
| Maximum AC Input Current | 43.5 A per phase | |
| BATTERY MODE OUTPUT (AC) | ||
| Nominal Output Voltage | 230 VAC (P-N) / 400 VAC (P-P) | |
| Efficiency (DC to AC) | >91% | |
| BATTERY & CHARGER | ||
| Nominal Battery Voltage/Charging Voltage Range | 384 VDC / 384 VDC ~ 480 VDC | |
| Maximum Charging Current | 80 A | |
| GENERAL | ||
| PHYSICAL | ||
| Dimension, D X W X H (mm) | 430 x 715 x 1021 | |
| Net Weight (kgs) | 223 | |
| INTERFACE | ||
| Communication Port | RS-232/USB | |
| Intelligent Slot | Optional SNMP, GPRS, WIFI, Modbus cards available | |
| ENVIRONMENT | ||
| Humidity | 0 ~ 90% RH (No condensing) | |
| Operating Temperature | -10 to 55°C | |
| Altitude | 0 ~ 1000 m** | |
