The Modbus card provides UPS and PV inverter systems with the functionality of communication with PCs through MODBUS protocol: 1. Implements MODBUS RTU protocol 2.Provides MODBUS functions including read Holding Registers and write Registers. 3. Provides RS232 and RS485 interface
Overview
Main Features
- Real-time control and monitoring of multiple UPSs or inverters via RS-232/RS-485 communication port
- Supports Modbus RTU protocol
- Built-in dip switch for RS-232 and RS-485 configuration
- Provides MODBUS functions including read Holding Registers and write Registers
- Provides surge protection
Specifications
| MODEL | Modbus | |
| Protocol | Modbus RTU | |
| Network Connection | RS-485 through isolated RJ45 port | |
| Baud Rate | 2400 bps/4800 bps/9600 bps/19200 bps | |
| Parity | Even/Odd/None | |
| Power Input | 12 V | |
| Net Weight (kgs) | 34.7 g | |
| Power Consumption | 0.5 watt (max.) | |
| Operating Temperature | 0~40°C | |
| Operating Humidity | 0~95% | |
| Dimension, D X W X H (mm) | 84 x 43 x 14 | |
